Spiral Dryer Screen

Small loop Suitable for line paper.

Medium loop Suitable for Board & Packing Paper.

Large loop Suitable for Board & Packing Paper.

Style	Product No.	Sing loop size(mm)	Diameter(mm)		Strength (N/cm)	Width (mm)	Weight (kg/m)	Air perm (m³/m²h)
Style	Product No.	Sing loop size(mm)	Spiral loop filament	String	Strength (N/cm)	Width (mm)	Weight (kg/m)	Air perm (m³/m²h)
Super large loop	70004	4.8*10	0.9	1.1	2300	3.03	1.64	2100±1000
large loop	70003	3.8*7.0	0.68	0.9	2000	2.45	1.40	1800±1000
Medium loop	70002	4.8*10	0.68	0.9	2000	2.45	1.31	1600±1000
Small loop	70001	3.2*5.2	0.5	0.8	1800	1.87	0.97	1400±1000

Other technical parameter
1.Shrink percentage: under 135°C, <1.5%; under 150°C, <2.0%.
2.Dimension varation: length: length<20m, error+4cm; length>20m, error+5cm; Width error:± 1cm.
3.Shrink percentage: <1%.
4.Width of edging material: 3.0~4.0cm.

Enquiry Us

Technical parameters of dryer fabric with flat yarn

Fabric Code	Wrap Mesh	Weft Count	Werp Diameter	Weft Diameter	Air Permeability /m³/m²h	CFM	FSI	DI
YGWS22604	23.0~24.0	14.5~15.5	0.815 x 0.31	0.40 0.60	1400	90	-	-
YGWS22604	23.0~24.0	13.0~14.0	0.815 x 0.31	0.40 0.60	2350	150	-	-
YGWS22604	18.5~19.5	15.5~16.5	0.58 x 0.38	0.60	2350	150	-	-
	18.5~19.5	14.5~15.5	0.58 x 0.38	0.60	4000	250	-	-
	18.5~19.5	13.0~14.0	0.58 x 0.38	0.60	5500	350	-	-
	18.5~19.5	11.5~12.5	0.58 x 0.38	0.60	7000	450	-	-
YGW18504-2	18.5~19.5	10.5~11.5	0.58 x 0.38	0.70	9500	600	-	-

Technical parameters of dryer fabric with flat yarn

Fabric Code	Wrap Mesh	Weft Count	Werp Diameter	Weft Diameter	Air Permeability /m³/m²h	CFM	FSI	DI
GW22504-3	23.0~24.0	13.5~14.5	0.50	0.50	7000	450	-	-
GW22504-3	23.0~24.0	13.0~14.0	0.50	0.50	8500	550	-	-
GW22504	23.0~24.0	10.5~11.5	0.50	0.50	12000	760	-	-
